Safe Drinking for All through Solar Disinfection

by Dr. Anumakonda Jagadeesh

Click Here (open in a new Window) to watch More


Every 8 seconds, a child dies from water related disease around the globe. 50% of people in developing countries suffer from one or more water-related diseases. 80% of diseases in the developing countries are caused by contaminated water. Providing safe drinking water to the people has been a major challenge for Governments in developing countries. Conventional technologies used to disinfect water are: ozonation, chlorination and artificial UV radiation. These technologies require sophisticated equipment, are capital intensive and require skilled operators (1,17,20). Boiling water requires about 1 kg of wood/liter of water which results in deforestation in developing countries. Also halazone or calcium hypochlorite tablets or solutions (sodium hypochlorite at 1 to 2 drops per liter) are used to disinfect drinking water. These methods are environmentally unsound or hygienically unsafe when performed by a layperson. Misuse of sodium hypochlorite solution poses a safety hazard (2,4,11).

Treatment to control waterborne microbial contaminants by exposure to sunlight in clear vessels that allows the combined germicidal effects of both UV radiation and heat has been developed and put into practice (5,712,13,14,18,19).The SODIS system(Solar Disinfection of water) developed by scientists at the Swiss Federal Agency for Environmental Science and Technology(EAWAG) recommends placing PET bottles (usually discarded mineral water/beverage bottles) painted black on one side, aerating (oxygenating) the water by vigorous shaking three fourths water filled bottles and then filling them full and placing them in sunlight for 6 hours. In this method, the water is exposed to UV radiation in sunlight, primarily UV-A and it becomes heated; both effects contribute to the inactivation of water borne microbes. The use of PET bottles requires periodic replacement because of scratches and they become deformed if temperature exceeds 65C. Also dust accumulates on these bottles in the groves (provided for strength). The PET bottle mineral water manufacturers print on the label,’ crush the bottle after use’ in
India. Unless cleaned thoroughly everyday, PET bottles turn brown over usage rendering lesser transmission of sunlight.

Microorganisms are heat sensitive. Table 1 lists up the required temperature to eliminate microorganisms within 1,6 or 60 minutes. It can be seen that it is not required to boil the water in order to kill 99.9% of the microorganisms. Heating up water to 50 - 60C (122 - 140F) for one hour has the same effect (2,21).

The most favorable region for solar disinfection lies between latitudes 15 0 N/S and 35 0 N/S. These semi-arid regions are characterised by high solar radiation and limited cloud coverage and rainfall (3000 hours sunshine per year).The second most favorable region lies between the equator and latitude 15 0 N/S, the scattered radiation in this region is quite high (2500 hours sunshine per year).

The need for a low-cost, low maintenance and effective disinfection system for providing safe drinking water is paramount, especially for the developing countries.

Materials And Methods

The innovative solar disinfection system has a wooden frame of length 2 ft,width 1 foot and depth 6 inches with bottom sinusoidal shaped polished stainless steel (curvature slightly larger than standard glass wine bottles, about 5 inches diameter) . On the front is fixed a glass sheet having lifting arrangement with a knob (this glass enclosure will protect the glass bottles from cooling down due to outside wind). There are screws which can be used to keep the contents airtight. On the backside a stand is fixed which will help the unit to be placed according to the latitude of the place for maximum solar insolation.

In this method clear glass bottles (used wine bottles) are utilised instead of PET bottles as the former are easy to clean, lasts longer and are available at a low cost in
India. Solar disinfection is more efficient in water containing high levels of oxygen; sunlight produces highly reactive forms of oxygen (oxygen free radicals and hydrogen peroxides) in the water. These reactive forms of oxygen kill the microorganisms. Aeration of water is achieved by shaking the 3/4 water filled bottles for about 20 seconds before they are filled completely.

The unit has an advantage in that the rear reflection stainless steel will pass the light through the bottles a second time, to both increase exposure and eliminate shadowing. This reflection system will increase the light intensity minimum 2 times.

It has been widely experimented and established by earlier researchers that at temperature of 50C (122F), pathogenic microbes are inactivated. The temperatures which cause approximately a 1-log decrease in viability with 1 min are 55C (131F) for protozoan cysts; 60C (140F) for E.coli, enteric bacteria, and rotavirus; and 65C (149F)for hepatitis A virus (3,6,8,9,10,16). Negar Safapour and Robert H.Metcalf (15) in their extensive studies reported enhancement of solar water pasteurization with reflectors and the crucial role of temperature above 50C (122F) in the elimination of pathogens.


The unit is placed in the south direction (in
India) around 10 am with inclination equal to the latitude of the place. The glass bottles are filled with water three fourths and shaken for 20 seconds to generate oxygen and then completely filled. The water filled bottles are fixed with caps and put in the groves of the solar disinfection unit. The glass door is closed and clipped airtight. Water bottles are removed from the unit at 3 pm and taken to a cool place and the disinfected water transferred to a clean vessel, covered for later usage.

Suspended particles in the water reduce the penetration of solar radiation into the water and protect microorganisms from being irradiated. Solar disinfection requires relatively clear water with a turbidity less than 30 NTU.To remove turbidity traditional methods of putting the paste from seed of strichnos potatorum (Nirmal seeds) by rubbing the seed on a rough stone with water is used. The method is effective, turbidity settles down in half ofv an hour and the seed are available in plenty in forests in
India besides being inexpensive.

Sample Testing

Water samples from the solar disinfection unit were tested with Most Probable Number (MPN) technique. To estimate the number of aerobic organisms present in water, Pour Plate Technique has been used.


The test results of various water samples disinfected are presented in Table 2. In the samples from Ambattur Bore Water, Ambattur Well Water, Anna Nagar Bore Water and Kavaraipettai Bore Water, since they are highly contaminated, further dilutions were not carried out. The dilution should be done only when the MPN indicates more than 1100 organisms/100 ml. For these samples only log reductions can be calculated. As regards R.S.M.Nagar Bore Water and Thathai Manji Well Water, the percentage of reduction are 85 and 86.95, which indicates that the water is less contaminated. As MPN index shows less than 3 organisms for 100 ml, after solar disinfection of water, the samples are free from coli forms. The results of Avadi Waste Water and Perambur Waste Water show 3 log reduction (99.8%) and 4 log reduction
(99.993%) respectively.

For comparison PET and Glass bottles were placed with black background as well as in the innovative device I developed. The results were presented in Table 3.

It can be readily seen that solar disinfection of water is complete with my device compared to open.


Eradication of coli forms from well water, bore water and waste water has been reported from test results. The results confirm that there is 4-log 10 reduction of coli forms in the waste water after solar disinfection. The experiments were conducted at Kavaraipettai,Tamil Nadu,India.Maximum temperature occurs around 1 pm. Though 6 bottles were used in the system(each of 1 liter capacity),larger units with up to 100 bottles can be designed. The unit destroyed 99.99% of bacterial coli forms both in well water and waste water samples in 5 hours.

The innovative solar disinfection system has the advantages like:

The unit is portable,
It is cost-effective.
It can be fabricated in
South India for US $20.
The unit incorporates the principle of reflection to increase solar intensity and has protection from wind which results in temperature rise inside the unit,
Larger units can be manufactured, Used glass bottles withstand higher temperatures and are available in plenty each for 2 US cents in South India, Since all the materials are available locally, the unit can be manufactured locally with local people.
Temperatures above 30C occur in south
India for more than 10 months in a year and as such this innovative solar disinfection unit will be a boon in this region.


The project is financially supported by Science and Society Division, Department of Science and Technology, Government of

Contact Info:

Dr.Anumakonda.Jagadeesh, Centre for Energy and
Sustainable Resources

R.M.K.Engineering College,Kavaraipettai 601 206,

Tamil Nadu,Ph: ++ 91 44 27925102,


Mobile: 09490125950


1. Acher,A., E.Fischer,R.Turnheim,and Y.Manor. Ecologically friendly wastewater disinfection techniques.Water Res. 31:1398-1404.(1997).
2. Pelizzetti, E.1999.Solar water detoxification.Current status and perspectives.Z.Phys.Xhem.212:207-218(1999).
3. U.S.Environmental Protection Agency..Ultraviolet light disinfection technology in drinking water application: an over view.EPA 811-R-96-002.U.S.Environmental Protection Agency,
Washington D.C.( 1996)
4. Acra,A.,M.Jurdi,H.Mu'allem,Y.Karahagopian,and Z.Raffoul.Water disinfection by solar radiation. Assessment and application.IDRC-TS66e.International Development Research Centre,
Ottawa,Canada. ISBN 0-88936-555-5 (p5),(1989)
5. Bunce,N.J. Environmental chemistry,p.183-214.Wuerz Publishing Ltd.,
6. Ishikawa,T.,T.Sato,Y.Ose.and H.Nagase.Reaction of chlorine and bromide with humic substance.Sci.Total Environ.54: 185-194(1986).
7. Wagelin,M., S.Canonica,K.Mechsner,T.Fleischmann,F.Pesaro, and A.Metzler. Solar water disinfection: scope of the process and analysis of radiation experiments.J.Water Supply Res. Technol.AQUA 43: 154-169(1994).
8. Calkins,J.,J.D.Buckles, and J.R.Moeller. The role of solar ultraviolet radiation in”natural” water purification.Photochem. Photobiol. 24: 49-57(1976).
9. Conroy,R.M., M.Elmore-Meegan,T.Joyce,K.G.McGuigan,and J.Barnes. Solar disinfection of drinking water and diarrhea in Maasai children: a controlled field trial.Lancet 348: 1695-1697(1996).
10. Joyce, T.M., K.G.Mcguigan, M.Elmore-Meegan, and R.M.Conroy, Inactivation of fecal bacteria in drinking water by solar heating. Appl.Environ.Microbiol.62: 399-402 (1996).
11. Sinton,L.W.,C.H.Hall,P.A.Lynch, and R.J. Davies-Colley. Sunlight inactivation of fecal indicator bacteria and bacteriophages from waste stabilization pond effluent in fresh and saline waters. Appl Environ Microbiol.68: 1122-1131(2002).
12. Jagger,J.Inhibition by sunlight of the growth of Escherichia coli b/r.Photochem.Photobiol.22: 67-70(1975).
13. Rijal,G.K.,Fujioka,R.S, Synergistic effect of solar radiation and solar heating to disinfect drinking water sources,Water Sci Technol.43: 255-162.
14. McGuigan.K.G.,Joyce.T.M,Conroy.R.M,Gillespie. J.B,Elmore-Meegan.M,Solar disinfection of drinking water contained in transparent plastic bottles: characterizing the bacterial inactivation process, J.Appl. Microbiol.84(6),1138-1148(1998).
Anderson,B.C., Moist heat inactivation of Cryptospordium sp. Am.J.Public Health 75:1433-1434 (Abstract)(1985).
16. Ciochetti,D.A., Metcalf.R.H. Pasteurisation of naturally contaminated water with solar energy.Appl.Environ.Microbiol.47:223-228(Medl ine)(1984).
17. Faechem,R.G., Bradley.D.J,Garelick.H,Mara.D.D,Sanitation and disease; health aspects of excreta and wastewater management,John Wiley & Sons,New York,N.Y(1983).
18. Fayer,R., Effect of high temperature on infectivity of Cryptospordium parvum oocysts in water.Appl.Environ.Microbiol.60: 2732-2735(Abstract)(1994).
19. Harp,J.A., Fayer,R.Pesch.B.A, Jackson.Effect of pasteurization on infectivity of Cryptosporidium parvum oocysts in water and milk.Appl.Environ.Microbiol. 62: 2866-2868(Abstract)(1996).
20. Parry,J.V., Mortimer. The heat sensitivity of hepatitis A virus determined by simple tissue culture method. J.Med.Virol.14: 277-283(Abstract)(1984).
21. Negar Safaour ., Metcalf,R.H,Enhancement of Solar Water Pasteurisation with Reflectors, Applied and Environmental Microbiology, 65, No.2,859-861(1999).
